In modern construction and fabrication, steel box section is one of the most widely used materials. Known for its strength, versatility, and efficiency, steel box section is a preferred choice for projects that demand both durability and clean design. From heavy-duty structural frameworks to furniture and architectural features, this type of hollow steel has become essential across many industries.

What is Steel Box Section?

A steel box section is a type of hollow structural steel with square or rectangular cross-sections. Unlike solid steel bars, these sections are hollow inside, which makes them lighter without compromising on strength. The flat surfaces of steel box sections also make them easy to cut, weld, drill, and join—qualities that are highly valued by builders and fabricators.

Steel box sections are usually produced in three main forms:

• Square Hollow Section (SHS) – Equal width and height, offering symmetry and balanced strength.
• Rectangular Hollow Section (RHS) – Wider than tall, delivering excellent load-bearing capacity and flat-sided stability.
• Circular Hollow Section (CHS) – Sometimes considered a type of box section for round profiles, useful for torsional strength and aesthetics.

Benefits of Steel Box Section

Steel box section has several advantages that make it a go-to choice in construction and manufacturing:

1. High Strength-to-Weight Ratio – Strong enough for heavy loads yet lighter than solid steel.
2. Ease of Fabrication – Flat surfaces allow for easy welding, cutting, and bolting.
3. Versatility – Suitable for structural, mechanical, and decorative applications.
4. Durability – Resistant to impact, bending, and environmental stress.
5. Cost-Effective – Reduces material use while maintaining structural integrity.

Steel Box Section Sizes and Dimensions

One of the greatest advantages of using steel box section is the wide range of sizes, wall thicknesses, and lengths available. This flexibility allows engineers, builders, and fabricators to select a section that matches the exact demands of their project—whether that’s a lightweight frame for a gate, a medium-sized section for fencing or balustrades, or a heavy-duty section for warehouse and bridge construction.

Square Hollow Section (SHS) Sizes

Square hollow sections are among the most popular types of steel box sections thanks to their balanced strength and symmetry. They perform well as columns, posts, and architectural supports.

• Small SHS sizes (ideal for light fabrication, furniture, and fencing): 15x15mm, 20x20mm, 25x25mm, 30x30mm, 35x35mm
• Medium SHS sizes (commonly used in construction frames, gates, and balustrades): 40x40mm, 50x50mm, 65x65mm, 75x75mm, 90x90mm, 100x100mm
• Large SHS sizes (suited for heavy-duty structures, warehouses, and industrial frameworks): 120x120mm, 150x150mm, 200x200mm, 250x250mm, 300x300mm
• Wall thickness range: 1.6mm to 16mm depending on the load requirements

Rectangular Hollow Section (RHS) Sizes

Rectangular hollow sections are particularly valued for their ability to carry directional loads efficiently. Their flat surfaces also make them easy to weld, bolt, and clad, which is why they are commonly used in construction and industrial projects.

• Small RHS sizes (used in light steelwork, shelving, and smaller structural elements): 40x20mm, 50x25mm, 60x30mm, 70x40mm
• Medium RHS sizes (widely used in residential and commercial buildings): 80x40mm, 100x50mm, 120x60mm, 150x75mm, 150x100mm
• Large RHS sizes (ideal for beams, trusses, bridges, and long-span structural frameworks): 200x100mm, 250x150mm, 300x200mm, 350x175mm, 400x200mm, 450x250mm
• Wall thickness range: 2.0mm to 20mm for heavy-duty applications

Other Variations of Steel Box Sections

While SHS and RHS are the most common, steel box sections can also come in custom shapes and special dimensions for niche applications:

• Heavy-wall box sections: Extra-thick walls up to 25mm for high-load and industrial projects.
• Light-gauge box sections: Thin-walled sections (around 1.2–1.6mm) for furniture, decorative structures, or partitions.
• Galvanised box sections: Coated with zinc for enhanced corrosion resistance, particularly in outdoor and marine environments.

Standard Lengths

Most steel box sections are supplied in 6m and 12m standard lengths. However, many suppliers offer cut-to-size services, allowing fabricators to order custom lengths to minimize waste and improve efficiency on-site.

👉 Why Sizes Matter:
Choosing the right steel box section size ensures the structure remains strong without being unnecessarily heavy or expensive. For example:

• A 25x25x1.6mm SHS may be perfect for a garden gate.
• A 100x100x6mm SHS could serve as a reliable column in a small building.
• A 300x200x10mm RHS may be essential for large spans in a warehouse or bridge.

By carefully selecting the correct size, builders can strike the right balance between performance, cost, and ease of fabrication.

Common Applications of Steel Box Section

Steel box sections are used across a wide variety of industries thanks to their adaptability:

• Construction: Structural frames, columns, beams, and trusses.
• Industrial: Machinery frames, storage systems, transport equipment, trailers.
• Architectural: Balustrades, railings, gates, staircases, decorative frameworks.
• Residential: Furniture, fencing, shelving, and general home improvements.
• Infrastructure: Bridges, warehouses, agricultural buildings, and transport hubs.

Why Choose Steel Box Section for Your Project?

Steel box section is one of the most versatile structural materials available today. Whether you’re working on a large industrial development or a small fabrication job, this material provides multiple advantages that make it a smart choice. Below are the key reasons why builders, architects, and fabricators consistently rely on steel box sections:

1. Exceptional Strength and Load-Bearing Capacity

• The hollow shape of both SHS (Square Hollow Section) and RHS (Rectangular Hollow Section) provides excellent strength-to-weight ratios.
• Box sections resist bending, torsion, and compression forces, making them suitable for beams, frames, and load-bearing columns.
• They offer uniform strength across both directions (especially SHS), giving balanced support in structural designs.

2. Wide Range of Sizes and Thicknesses

• Available in small, medium, and large dimensions to suit every type of project.
• Wall thicknesses range from 1.6mm to over 20mm, offering flexibility between lightweight applications and heavy-duty construction.
• Common lengths include 6m and 12m, but many suppliers provide custom cut-to-size options for efficiency.

3. Multiple Material Options

• Mild Steel Box Section: Affordable and easy to weld, cut, and fabricate—perfect for general construction and manufacturing.
• Stainless Steel Box Section: Offers excellent corrosion resistance and a polished appearance, making it ideal for architectural features and outdoor use.
• Galvanised Box Section: Zinc-coated for maximum rust protection, best for fencing, gates, and marine or outdoor applications.

4. Design Flexibility and Aesthetic Appeal

• The clean, geometric lines of steel box sections make them a popular choice in modern architecture and interior design.
• They can be used in decorative balustrades, furniture, pergolas, and exposed structural elements.
• Easily combined with glass, wood, or composite materials for striking visual effects.

5. Ease of Fabrication and Installation

• Flat surfaces make box sections easy to weld, bolt, or rivet.
• They are lightweight relative to their strength, making handling and installation faster and more efficient.
• Available in standard sizes globally, ensuring consistency and easy replacement.

6. Durability and Longevity

• Resistant to warping, splitting, or insect damage compared to timber alternatives.
• With proper finishing (galvanisation, powder coating, or paint), steel box sections can last decades even in harsh outdoor conditions.
• High resistance to impact and vibration, making them suitable for both static and dynamic structures.

7. Sustainability and Eco-Friendly Choice

• Steel is 100% recyclable without losing its properties.
• Using steel box sections supports green building practices by reducing waste.
• Many construction projects choose steel box sections to meet sustainability certifications such as LEED.

Steel Box Section in Perth

If you’re looking for steel box section in Perth, you’ll find that local suppliers provide a wide range of SHS and RHS options to suit residential, commercial, and industrial projects. Builders and fabricators in Perth rely on steel box sections because of their proven strength, easy fabrication, and long-lasting durability in Australia’s diverse climate. Whether you need mild steel, stainless steel, or galvanised box section, suppliers across Perth can deliver cut-to-size options for fast installation and reduced waste. With standard lengths like 6m and 12m, plus various wall thicknesses from light to heavy duty, Perth customers can easily source the right material for fencing, structural frames, mining infrastructure, and even decorative architectural designs. Choosing a trusted Perth steel supplier ensures competitive pricing, quick delivery, and expert advice for your next project.
